22mm Mini Indicator Lights Ammeter and voltmeter multi signal lamp

Product Categories

YUEQING RENHE ELECTRIC CO., LTD.

Contact Now

Name: 22mm Mini Indicator Lights Ammeter and voltmeter multi signal lamp
Brand: Customized
Price: 1.50 USD

Place of Origin : Zhejiang, China

Brand Name : Customized

Model Number : AD101-22VAM

Display Type : Digital Only

Measuring Range : 0-100a & 50-500v

Accuracy Class : 0.5 Class

Supply Voltage : None

Operating Temperature : -10℃~+55℃

Dimensions : 22mm

color : White/Red/Yellow/Blue/Green

accuracy : 0.5 class

Accessories : Current Transformer included

display : LED 3 digits display

brand : rehe

measure : 0-100a & 50-500v

usgae : indusrial

material : PBT

Warranty : 1 Years

Display mode : 3 Digits

Packaging Details : Packaging Detail:500pcs/carton
Gross Weight:25KGS/CTN
Inner box+Master Carton

Port : ningbo shanghai

Supply Ability : 1000000 Piece/Pieces per Month

Price : $1.50 - $2.00/pieces

Contact Now

22mm Mini Indicator Lights Ammeter and voltmeter multi signal lamp

Brand:	REHE(OEM is available) or Netural without any brand
Item Name:	Indicator Light(pilot light)Voltmeter
Item No.	AD101-22VAM
Current Range:	AC 20-500Vac &0-100Aac
Operating frequency:	50/60Hz
Diameter:	22mm
Color:	R-red, Y-yellow, B-blue, G-green, O-orange, W-white;
Standard Package:	Color Box
Beam Angle:	360°
Advantages:	Accurate Reading/Durable in Use/Energy Conservation/High Brightness Digital Display
Enclosure Material:	PBT
Rated Tem:	T90
Working Life:	Typically over 30,000 hours. The end of life for a lamp is not usually a sudden failure;
Ambient Temperature:	-25+55℃;
Relative Air Humidity:	≤98%;
Pollution rank:	grade 3
Installation category:	III
Withstand Voltage of working frequency:	2.5kV/1min(AC valid value);
Insulatioin resistance:	≥2MΩ
Allowable voltage fluctuation:	≥20%
Leakage Index:	CT1≥600;
Brightness:	≥100cd per square meter
Frequency:	AC 50-60Hz
Working under vibration frequency 2-80Hz and acceleration at 0.7g is available;

22mm Mini Indicator Lights Ammeter and voltmeter multi signal lamp

22mm Mini Indicator Lights Ammeter and voltmeter multi signal lamp Images
